Craftsman 247.770550 User Manual
Page 21
21
Sears Craftsman 6.0 H.P. Yard Vacuum Model 247.770550
Ref.
No.
Part No.
Part Description
1.
664-0094
Bag Assembly
2.
681-0154
Screen Assembly
3.
710-1054
Hex Screw 5/16-24 x 1.0
4.
781-0490
Chipper Blade
5.
719-0530A
Impeller
6.
781-0735
Pin Clip
7.
719-0329
Flail
8.
715-0166
Spiral Pin
9.
711-1401
Clevis Pin
10.
712-0411
Lock Nut, 5/16-24
11.
736-0119
Lock Washer, 5/16
12.
681-0152
Impeller Assembly
(Incl. Ref 3 – Ref. 11)
13.
710-1238
Hex Cap Screw 5/16-18 x .875
14.
781-0721A
Lower Housing
15.
712-3004A
Flange Lock Nut 5/16-18
16.
712-3027
Hex Flange Nut 1/4-20
17.
736-0142
Flat Washer .281 ID x .50 OD
18.
714-0225
Cotter Pin
19.
711-1560
Pivot Rod
20.
731-2294
Nozzle
21.
781-1064
Base Adapter Door
22.
732-1156
Torsion Spring
23.
726-0106
Cap Speed Nut 1/4
24.
711-1551
Pivot Rod
25.
712-0161
Hex Lock Nut #10-24
26.
736-0400
Flat Washer .194 ID x .62 OD
27.
731-2485
Nozzle Door Lever
28.
710-1156
Hex Screw #10-24 x 1.25
29.
750-1294
Shoulder Spacer
30.
732-3118
Extension Spring
31.
732-1151
Torsion Spring LH
32.
732-1150
Torsion Spring RH
33.
731-2294
Nozzle Door
34.
711-1582
Rod .25 x 1.25 Lg
35.
781-0725A
Front Wheel Support Brace
36.
781-0777
Rear Wheel Support Brace
37.
681-0155
Handle Bracket Ass”y LH
681-0156
Handle Brkt Ass”y RH (Not Shown)
38.
714-0104
Cotter Pin
39.
710-3025
Hex Cap Screw 5/16-18 x. 625
40.
736-0105
Bell Washer.401 ID x.870 OD
41.
734-04007
Wheel 9 x 2
42.
736-0232
Wave Washer .531 ID x .781 OD
43.
738-1015
Shoulder Screw 3/8-16
44.
731-0981A
Hubcap
45.
781-0785
Height Adjustment Bracket
46.
738-1185
Stud 5/16-18 .56 x .75
47.
741-0751
Height Adjustment Bearing
48.
682-0113
Pivot Arm Assembly
49.
720-0426
Height Adjustment Knob
50.
732-1026
Spring Lever
51.
736-0741
Bell Washer .760 ID x .25 OD
52.
738-1173
Shoulder Screw .750 ID x .625 OD
53.
734-1978
Wheel 8 x 2
54.
712-0431
Flange Lock Nut 3/8-16
55.
726-0453
Lock Nut 3/8-16
56.
712-0158
Hex Lock Nut 5/16-18
57.
736-0314
Thrust Washer .375 ID x .70 OD
58.
631-0090
Blower Chute
59.
764-0631
Bag
60.
631-0083
Chute Assembly
61.
710-1260A
Hex Index Screw, 5/16-18 x .75
62.
736-0247
Flat Washer.375 ID x 1.25 OD
63.
736-0217
Lock Washer 3/8
64.
710-0818
Hex Cap Screw 3/8-24 x 2.0
Ref.
No.
Part No.
Part Description
NOTE: For painted parts, please refer to the list of color codes below. Please add the applicable color code, wherever needed,
to the part number to order a replacement part. For instance, if a part, numbered 700-xxxx, is painted Sears Red, the part num-
ber to order would be 700-xxxx-0721.
Sears Red:
0721
Oyster Grey:
0662
Powder Black:
0637
