Lukas LKS 55 EN User Manual
Combi tools series lks, Operating instructions rescue tools
1
Combi tools Series LKS
84150/6239-85 GB
Issue 09.2005
replaces 08.2003
Operating Instructions
Rescue Tools
1
Control valve with star shape ring
2
Hydraulic cylinder
3
Protecting hose
4
Central bolt with selflocking nut
5
Cutter blades
6
Handle
7
Handle
8
Quick-connect socket
9
Hose, red:
Pressure
10
Quick-connect plug
11
Hose, blue:
Return
11
10
1
9
8
3
4
5
2
6
7
