bühler
Allied Front-End Loader
-
37 -
P4110
2895 TSL – 2895 S TSL
Main Frame Assembly
Item Part No.
Description
2895 TSL 2895 S TSL
1 24967
2895 TSL Main Frame Weldment
1
-
1 24945
2895 S TSL Main Frame Weldment
-
1
2 25165
2895 Quick Attach Weldment
1
1
3
Ref.
Lift Cylinder (see cylinder assembly)
2
2
4
Ref.
Bucket Cylinder (see cylinder assembly)
2
2
5 115585
Pin Weldment (Quick Attach)
2
2
6 24942
Upright Weldment Right (TSL)
1
1
7 24941
Upright Weldment Left (TSL)
1
1
8 115527
Pin Weldment (Upright)
2
2
9 115473 Pivot
Plate
2
2
10 115583
Leveling Tube Weldment
2
-
10 115475
Leveling Tube Weldment
-
2
11 116344 Link
Weldment
17.0"
4
4
12 116343
Link Assembly 10.5"
4
4
13 116349
Link Spacer 2.0 OD x 2.5 LG.
2
2
14 115486 Stand
Tube
2
2
15 114303 Stand
Foot
2
2
16 115906
Pin 1.25 x 6.75
10
10
17 115904
Pin 1.25 x 6.25
4
4
18 115900
Pin 1.25 x 5.25
2
2
19 115908
Pin 1.50 x 6.75
2
2
20 113579
Bushing 1.50 ID x 1.88 OD
4
4
21 113633
Bushing 1.25 ID x 1.63 OD
20
20
22 113691
Bushing 1.25 ID x 1.63 OD x 0.75 LG
8
8
23 12779
Hair
Pin
Clip
6
6
24 110907 Stand
Pin
2
2
25 81669
Hex Bolt 0.625 DIA x 3.5 LG.
2
2
26 81967
Nut Lock 0.625 DIA
6
6
27 81344
Nut Lock (Nylon) 0.375 NC
9
9
28 81570
Flat Washer 0.375 DIA
4
4
29 24242
Cross Tube Cover
1
1
30 81592
Nut Hex 0.375 NC GR2 PL
4
4
31 81637
Lock Washer 0.50 DIA
2
2
32 813228
Wing Nut 0.50 DIA
2
2
33 115909 Pin
Cap
22
22
34 81615
Washer Lock 0.438 DIA
22
22
35 81597
Hex Bolt 0.438 DIA x 1.00 GR5 PL
22
22
36 115564
Leveling Rod
1
1
37 81966
Nut Lock (Nylon) 0.50 NC
2
2
38 114969 Guide
Bracket
1
1
39 115012 U-Bolt
1
1
40 116347
Pin 1.25 x 7.25
4
4
