Page 52
Item
Part No.
Qty.
Description Of Part
23
8855-1013
11"
5/16, HOSE
24
8856-1111
1
FLAT WASHER, 1/2
25
9114-3122
1
SUPPORT CLAMP, 5/8
26
8319-1004
2
HEX HD CAPSCREW, M12X1.75X30,
GR8
27
8319-1010
2
LOCKWASHER, M12
28
9108-3481
1
NEGATIVE BATTERY CABLE
29
9108-3482
1
POSITIVE BATTERY CABLE
30
9002-7187
1
TY-RAP
31
8871-1284
1
HEX SOCKET PIPE PLUG, 3/4
32
9020-5792
1
CUSHION CLAMP
33
8866-1384
1
HEX HD PLUG, 3/8 TUBE,
34
9134-5008
1
STARTER RELAY ASSEMBLY,
(includes the following seven items)
7738-3377
2
SOLENOID RELAY
8821-1028
4
HEX HD CAPSCREW, #10-24X1/2,
GR8
8850-1612
4
HEX NUT, #10-24
8855-1007
4
LOCKWASHER, #10
8856-1105
4
FLAT WASHER, #10
9133-1014
1
RELAY MOUNTING PLATE
9137-3009
1
JUMPER WIRE
35
9136-3066
1
JUMPER WIRE
36
9108-3504
1
REGULATOR
37
9114-3314
1
WATER TEMPERATURE SENDER
38
8871-1385
1
REDUCER BUSHING, 1/2X1/8
39
2486-1170
3
SUPPORT CLAMP
NOTE: ONLY ITEMS WITH PART
NUMBERS ARE AVAILABLE
FOR SERVICE.
5-2
Item
Part No.
Qty.
Description Of Part
9139-5007
Ref
ENGINE ASSEMBLY, (includes all
items on page 5-1 except 49 thru 55;
includes items 1 thru 39 on page 5-2,
and all items on page 5-3)
1
9133-3004
1
TUBE ASSEMBLY
2
8471-2738
2
SPLIT FLANGE CLAMP
3
8320-1135
4
HEX HD CAPSCREW, 7/16-14X1-1/2,
GR8
4
8855-1012
4
LOCKWASHER, 7/16
5
8820-1018
2
HEX HD CAPSCREW, 5/16-18X-3/4,
GR8
6
8850-1005
2
HEX NUT, 5/16-18
7
9109-1001
1
CLAMP SUPPORT
8
8855-1010
2
LOCKWASHER, 5/16
9
9108-3106
1
O-RING
10
Ref
EXHAUST TUBING & ATTACHING
PARTS, (see page 5-8 for details)
11
8319-1021
13
HEX HD CAPSCREW, M10X1.5X30,
GR8
12
8319-1013
16
LOCKWASHER, M10
13
9133-6003
1
TUBE SUPPORT
14
9108-6131
1
TUBE SUPPORT
15
9108-3456
1
STARTER
16
9108-3503
1
ALTERNATOR, (includes item 36)
17
9114-6058
1
FLOW DIVIDER BRACKET
18
8319-1006
1
HEX HD CAPSCREW, M10X1.5X40,
GR8
19
8856-1109
3
FLAT WASHER, 3/8
20
8319-1005
2
HEX HD CAPSCREW, M10X1.5X45,
GR8
21
8348-3497
2
HOSE CLAMP
22
9002-8660
2
SUPPORT CLAMP
ENGINE & ATTACHING PARTS
(9139-5007) EPA Engine Right Side View
Starting Serial No. 0191001
Original Issue 6-01
SERVICE NOTES:
1). Use Loctite, P/N 1440-3364, on all bolt
& fitting threads except pipe threads.
2). Use Loctite pipe sealant, P/N 1440-4082, on
all pipe threads.
3). Add 12 qts. of oil, P/N 1440-3420, to crankcase.
