1 - 2 INTRODUCTION
DCP part names and operations
■
Front view
No. Name Description
1 (DCP-8020) Manual Feed Tray
(DCP-8025D) Multi-purpose Tray
(MP Tray)
Load paper here.
2 Front Cover Release Button Press it to open the front cover.
3 Face-down Output Tray Support Flap
with Extension (Support Flap)
Unfold it to prevent the printed paper
from sliding off the DCP.
4 Automatic Document Feeder (ADF) Use the ADF unit for multiple page
documents.
5 ADF Document Support Extension Place the document here to use the
ADF unit.
6 ADF Document
Output Support Flap
7 Document Cover
5 ADF Document Support
Extension
4 Automatic Document Feeder (ADF)
11 Paper Tray (Tray #1)
3 Face-down Output Tray
Support Flap with Extension
1 (DCP-8020) Manual Feed Tray
(DCP-8025D) Multi-purpose
Tray (MP Tray)
9 Power Switch
10 Front Cover
2 Front Cover Release Button
8 Control Panel
