12H800
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
0990–16 Assemblies include all parts shown in frames. 6C–6/2002
36
801 690782 Cap–Drive
802 695267 Cap–End
(Used After Code Date
00040600).
––––––– Note –––––
695975 Cap–End
(Used Before Code
Date 00040700).
803 695266 Housing–Starter
(Used After Code Date
00040600).
––––––– Note –––––
695975 Housing–
Starter
(Used Before Code
Date 00040700).
832 499034 Guard–Muffler
832A 691424 Guard–Muffler
832B 497683 Guard–Muffler
836 690664 Screw
(Muffler Guard)
836A 690661 Screw
(Muffler Guard)
836B 691147 Screw
(Muffler Guard)
842 K 691031 Seal–O Ring
(Dipstick Tube)
843 691884 Sleeve–Lever
(Speed Control)
843A 691895 Sleeve–Lever
(Choke)
847 692017 Dipstick/Tube
Assembly
––––––– Note –––––
692047 Dipstick/Tube
Assembly
Used on Type No(s).
1720.
851 493880 Terminal–Spark Plug
853 695268 Adapter–Wire
869 691155 Seat–Valve
(Intake)
870 690380 Seat–Valve
(Exhaust)
871 262001 Bushing–Valve Guide
(Exhaust)
––––––– Note –––––
63709 Bushing–Valve
Guide
(Intake)
883 K∅ 691881 Gasket–Exhaust
892 690646 Switch–Key
910 691094 Stud
(Alternator)
921 497233 Cover–Blower Housing
(Static Guard) (5.5)
––––––– Note –––––
692933 Cover–Blower
Housing
Used on Type No(s).
1520, 1530, 1531,
1567, 2611, 2612,
2630, 2631, 2667,
2678.
921A 695886 Cover–Blower Housing
(Black)
921B 692931 Cover–Blower Housing
(Static Guard) (XTE)
Used on Type No(s).
2320, 2331, 2626,
2391, 2396.
921C 695889 Cover–Blower Housing
(Static Guard)
(Satin Black)
Used on Type No(s).
2324, 2384, 2385,
2386, 2387, 2388,
2389, 2390, 2394,
2395.
921E 696262 Cover–Blower Housing
921F 697343 Cover–Blower Housing
922 691831 Spring–Brake
922A 692135 Spring–Brake
923 691994 Brake
923A 695891 Brake
925 690595 Cover–Linkage
930 691919 Guard–Rewind
(Round)
930A 691345 Guard–Rewind
(Teardrop)
935 499421 Switch–Interlock
(Used After Code Date
92100600).
––––––– Note –––––
398758 Switch–
Interlock
(Used Before Code
Date 92100700).
937 691325 Spline–Starter
940 690664 Screw
(Casing Clamp
Bracket)
957 397974 Cap–Fuel Tank
(Plastic)
(Black)
––––––– Note –––––
692662 Cap–Fuel
Tank
(Plastic)
(Red)
Used on Type No(s).
2384, 3312.
957A 692046 Cap–Fuel Tank
(Plastic)
966A 496116 Base–Air Cleaner
Primer
967A 493537 Filter–Pre Cleaner
968B 692298 Cover–Air Cleaner
969 690700 Screw
(Blower Housing
Cover)
969A 691138 Screw
(Blower Housing
Cover)
K Included in Engine Gasket Set–Ref. No.358.
D
Included in Carburetor Overhaul Kit–Ref. No. 121.
z Included in Carburetor Gasket Set–Ref. No. 977.
∅ Included in Valve Gasket Set–Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
