Brother FAX-8050P User Manual
Page 5
REF.NO.
CODE
Q'TY
DESCRIPTION
REMARKS
1
SCANNER FRAME ATTACHMENT
2
LH0698001
1
GEAR DRIVE UNIT
(2-1)
LH0695001
1
PAPER FEED SOLENOID ASSY
3
UL6300003
1
MULTI-PURPOSE SHEET FEEDER, WHITE(1397) FOR FAX8050P/8250P
3
UL6300004
1
MULTI-PURPOSE SHEET FEEDER, WHITE(1138) FOR MFC9050/9550
4
UU7134001
1
LASER UNIT
5
UU7442001
1
HEAT-FIXING UNIT, 240V
5-1
UL6880001
1
FU LAMP, 240V
(5-2)
UL6667001
1
THERMISTOR ASSY
(5-3)
UL6681001
1
PINCH ROLLER ASSY
(5-4)
UL6682001
4
PINCH ROLLER SPRING
6
UG4557001
1
LOW-VOLTAGE POWER SUPPLY PCB ASSY, 230V(WITHOUT AC CORD)
7
087412016
3
TAPTITE, CUP B M4X20
8
087311016
2
TAPTITE, CUP B M3X10
9
UG4220001
1
TONER SENSOR PCB ASSY
10
087310815
1
TAPTITE, CUP B M3X8
11
UG4635001
1
TONER SENSOR HARNESS
12
085411215
3
TAPTITE, BIND B M4X12
13
UU7043001
1
SCANNER SPONGE
14
085411215
1
TAPTITE, BIND B M4X12
15
UU7044002
1
MAIN COVER ASSY, WHITE(1397) FOR FAX8050P/8250P
15
UU7044001
1
MAIN COVER ASSY, WHITE(1138) FOR MFC9050/9550
16
UL6887001
1
EL BOARD
17
087320616
1
TAPTITE, CUP S M3X6
18
085411215
1
TAPTITE, BIND B M4X12
19
LH0367001
1
FAN
20
UU7054001
1
FAN SUPPORT
21
UU7055001
1
INSULATION FILM
22
085411215
1
TAPTITE, BIND B M4X12
23
UU7056001
1
REGISTRATION SENSOR ACTUATOR
24
UU7057001
1
SHEET FEEDER COVER SENSOR ACTUATOR
25
UU7058001
1
TOP COVER SENSOR ACTUATOR
26
UG4509001
1
SPEAKER
27
085411215
1
TAPTITE, BIND B M4X12
28
087320616
1
TAPTITE, CUP S M3X6
29
UF6559001
1
SCREW, PAN (WASHER) M4X8DB
30
UU7062001
1
BOTTOM PLATE
31
UD4019001
2
RUBBER FOOT
32
085411215
7
TAPTITE, BIND B M4X12
33
087320616
3
TAPTITE, CUP S M3X6
34
002300616
2
SCREW, PAN M3X6
35
UU7064001
1
OPTION COVER
36
0A5300805
2
SCREW, PAN (S/P WASHER) M3X8
37
UU7322001
1
SPACER 30X145
38
UL6717001
1
PAPER EJECTION SENSOR ACTUATOR
39
UF8165003
1
UPPER HANDSET MOUNT, WHITE(1138) FOR MFC9550
40
UF8166003
1
LOWER HANDSET MOUNT, WHITE(1138) FOR MFC9550
41
UG5030001
1
HOOK SWITCH PCB ASSY FOR MFC9550
42
UF8167003
1
ACTUATOR HOOK, WHITE(1138) FOR MFC9550
43
UG4500001
1
HOOK SWITCH HARNESS FOR MFC9550
44
087311016
2
TAPTITE, CUP B M3X10
45
UU7065001
1
SCANNER GROUNDING PLATE
46
087310815
1
TAPTITE, CUP B M3X8
47
UF7676001
1
ANTI-STATIC BRUSH
48
UG3732001
1
BATTERY ASSY
FAX8050P/FAX8250P/MFC9050/MFC9550, Ver.Q
