Parallel Cable Connection for IBM-PC/AT or Compatible
Computers and IBM-PS/2 Computers
Signal Printer Pin No. Computer Pin No.
DATA STROBE
1 1
DATA 0 2 2
DATA 1 3 3
DATA 2 4 4
DATA 3 5 5
DATA 4 6 6
DATA 5 7 7
DATA 6 8 8
DATA 7 9 9
ACKNLG
10 10
BUSY 11 11
PE 12 12
SLCT 13 13
AUTO FEED
14 14
GND 19 - 30 18 - 25
FAULT
32 15
SLCT IN
36 17
