Parts Diagrams
4.
78-7876 76mm Reflector
1. Wide Field Finderscope
2. Telescope Main Tube
3. Primary Mirror (Internal)
4. Fine Adjustment Cables
5. Latitude Lock Knob
6. Horizontal Axis Lock Knob
7. Tripod Leg
8. Accessory Tray Brace
9. Quick-Release Accessory Tray
10. Quick-Release Tripod Leg Lever
11. Declination Lock Knob
12. Counterweight Shaft
13. Counterweight
14. Fine Adjustment Cables
15. Right Ascension Lock Knob
16. Rack and Pinion Focusing Mechanism
17. Eyepiece
18. Finderscope Mount
Telescope Parts Diagram
