Boss Audio Systems BR-600 - Manual (Page 174)

174
With Windows
Re
v0.10
You can import WAV and AIFF files on your computer and
load these as drum sounds (TONE LOAD).
1
Connect your computer and the BR-600 with a USB
cable.
2
Confirm that [PAD] is not lit, and with the recorder
stopped, press [UTILITY].
3
Press CURSOR [ ] [ ] to move the cursor to
“USB,” and press [ENTER].
The USB screen appears in the display.
4
Select “BACKUP” with the TIME/VALUE dial, then
press [ENTER].
The Idling screen appears in the display.
fig.05-370
* You cannot carry out the following procedure unless the
Idling screen is displayed. Refer to p. 214 for instructions on
resolving this problem.
The “BOSS_BR-600” (or “Removable disk (*:)”) icon is
added to the computer.
fig.05-060
5
Import the WAV or AIFF file.
1) Click the “BOSS_BR-600” (or “Removable disk
(*:)”) icon.
2) Drag the imported WAV or AIFF file to the
“TONELOAD” folder in the “ROLAND” folder.
fig.05-390
When you have finished importing the WAV or AIFF
files, the Idling screen returns to the display.
Loading Drum Sounds from
WAV/AIFF Files (Tone Load)
● Wave data in the following formats can be imported.
You cannot import wave data in other formats.
• WAV or AIFF format
• Mono or Stereo
• 8-bit or 16-bit
• Sampling Rate: 44.1 kHz
● Compressed WAV files or AIFF files cannot be
loaded.
● Extremely short waveform data (less than
approximately 100 ms) cannot be loaded.
● The loop point settings within an AIFF file will be
ignored.
● For the files to be imported, add the extension
“WAV” to WAV files and the extension “AIF” to
AIFF files.
● You can load drum sounds of up to 13 seconds for a
single drum kit.
(Example)
Kick: 3 seconds, snare: 3 seconds, crash cymbal: 7 seconds
→ Total 13 seconds
● Stereo WAV and AIFF files imported with Tone
Load are loaded as “mono” sounds with the left and
right sides mixed.
BOSS_BR-600 Removable Disk (*:)
(Ex.)
