Atlantic Technology WA-50 - Manual

CAUTION: To reduce the risk of electric shock, do not remove the cover (or back). No
user serviceable parts inside. Refer to qualified personnel.
WARNING: To reduce the risk of fire or electric shock, do not expose this appliance to
rain or moisture. This device generates a fair amount of heat. Make sure nothing blocks
the ventilation to the rear panel of the unit.
The lightning flash with arrowhead, with in an equilateral triangle, is intended
to alert the user to the presence of uninsu lated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to constitute a risk of
electrical shock to persons.
The exclamation point within an equilateral triangle is intended to alert
the user to the presence of important operating maintenance (servicing)
instructions in the literature accompanying the appliance.
The contents of this manual are Copyright © 2010 by Atlantic Technology
International, Corp., and may not be duplicated or reproduced by any means,
whether physical, electronic or otherwise without prior written consent from Atlantic Tech-
nology International, Corp.
Atlantic Technology and the Atlantic Technology logo are registered trademarks of Atlantic
Technology International, Corp.
Specifications are those in effect at the time of printing. Atlantic Technology International,
Corp. reserves the right to change specifications or designs at any time without notice
without obligation to modify existing units.
Safety Precautions
Instruction Manual
WA-50
Wireless Audio System
WA-50-t
Wireless Transmitter
WA-50-r
Wireless Receiver
WA-50-t
Wireless Transmitter
WA-50-r
Wireless Receiver
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation
Changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reason-
able protection against harmful interference in a residential installation. This equipment
generates and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
To satisfy FCC RF exposure requirements, a separation distance of 20 cm or more should
be maintained between this device and persons during device operation.
To ensure compliance, operations at closer than this distance is not recommended. The
antenna used for this transmitter must not be co-located in conjunction with any other
antenna or transmitter.
WA-50 Wireless Audio System
Congratulations on the purchase of an Atlantic Technology WA-50
Wireless Audio System. Never before has it been so easy to distribute
audio from one location in your home or business to another than it
is right now.
In this document, we will walk you through the installation of the
WA-50 system in just a few of the configurations that are possible with
this high performance wireless audio distribution system.
Specifications

Wireless full CD quality sound

Robust and dedicated network for your audio

Easy setup, get wireless music in seconds

Wireless range up to 50 m.; 100 m in line of sight

No interference or delays

Time delay max 10ms

Works with both Mac & PC

Plug'n play - No software needed

Flexible multi-zone functionality

RF band: 2.4GHz

Dedicated proprietary protocol

USB 2.0 interface

SNR: 93dB
If your product needs service, please call Atlantic Technology
at 781-762-6300.
You will need to present the original bill of sale to establish
the date of purchase. In the event that the proof of purchase
cannot be established with the original receipt, the warranty
period shall be determined by the earliest date of manufac-
ture shown on the unit.
In the event that you wish to return your Atlantic Technology
Product back to us, for any reason, please call to arrange for
a Return Authorization Number. This will ensure that your
problem is discussed with a service technician who will deter-
mine if there is a quick solution to your problem.
Atlantic Technology shall not be liable for, in any way respon-
sible for, any incidental or consequential damages of any kind.
Some states do not allow limitations on how long an implied
warranty lasts and/or do not allow the exclusion of inciden-
tal or consequential damages; therefore, the limitations and
exclusions stated herein may not apply to you. This warranty
gives you specific legal rights; and you may also have other
rights that vary from state to state.
THERE ARE NO WARRANTIES GIVEN BY ATLANTIC
TECHNOLOGY THAT EXTEND BEYOND THE DESCRIP-
TION GIVEN HEREIN. ANY IMPLIED WARRANTIES OF
FITNESS FOR PURPOSE SOLD, MERCHANTABILITY,
DESCRIPTION, QUALITY OR ANY OTHER MATTERS ARE
LIMITED TO THE TERMS OF THE EXPRESSED LIMITED
WARRANTY STATED HEREIN.
Products are sold on the basis of specifications applicable at
the time of sales. Atlantic Technology shall have no obligation
to modify products once they have been sold. This warranty is
applicable only in the United States. For applicability in other
countries, please call Atlantic Technology.
015-0050
343 Vanderbilt Avenue, Norwood, MA 02062
(781) 762-6300 www.atlantictechnology.com
Limited Warranty
This warranty protects the owner of the Atlantic Technology
Wireless WA-50-t and WA-50-r (the PRODUCT) for one (1)
year from the date of purchase.
This warranty covers all defects in material and workmanship
with the following specific exceptions. These are:

Damage caused by improper
installation or adjustment

Damage caused by acci-
dent, unreasonable use or
neglect

Damage from failure to fol-
low instructions contained
in this Instruction Manual

Damage occurring during
shipment

Damage from the per-
formance of repairs by
someone not authorized by
Atlantic Technology

Any unit on which the serial
number has been effaced,
modified, or removed

Units which have been al-
tered or modified in design,
appearance or construc-
tion.
This warranty covers only the actual defects within the PROD-
UCT itself. IT DOES NOT cover costs of installation in (or
removal from) a fixed installation, or normal setup, claims
based on any misrepresentation by the seller, or performance
variations resulting from installation related circumstances
such as signal quality, AC power or incompatibilities with
speakers and/or other system components.
During the warranty period, Atlantic Technology will, at its
option, either repair the defect, or replace the defective prod-
uct, or the defective parts, or components thereof at no charge
to the owner for parts and labor covered by this warranty If
necessary repairs are not covered by this warranty, or if a unit is
examined which is not in need of repair, you will be charged for
the repairs and/or the examination. If non-warranted repairs
are needed, we will notify you of the estimated cost and ask
for your authorization to perform said repairs.
You must pay shipping charges incurred in getting your Prod-
uct to the factory. We will pay the return shipping charges if
the repairs are covered by the warranty. Please save the original
shipping cartons, as the unit MUST be returned in the origi-
nal carton and packing. (Replacement cartons are available at
a modest charge.)
Your WA-50 Wireless Audio System ships with this Instruction
Manual and the following items:
WA-50-r Wireless
Receiver
WA-50-t Wireless
Transmitter
WA-50-r
Wireless Receiver
WA-50-t
Wireless Transmitter
2x USB AC Power
Adapters
NOTE: Please contact customer service if any of these items are missing.
2 x 1/8” Stereo Cables
2 x USB cords
2 x 1/8” Mono to RCA Cables
1 x 1/8” Stereo to RCA Cable
Safety Instructions

Read these instructions.

Keep these instructions.

Heed all warnings.

Follow all instructions.

Do not use this apparatus near
water.

Clean only with dry cloth.

Do not block any ventilation
openings. Install in accordance
with the manufacturer’s in-
structions.

Do not install near any heat
sources such as radiators, heat
registers, stoves, or other ap-
paratus that produce heat.

Protect the power cord from be-
ing walked on or pinched par-
ticularly at plugs, convenience
receptacles, and the point where
they exit from the apparatus.

Only use attachments/acces-
sories specified by the manu-
facturer.

Unplug this apparatus during
lighting storms or when unused
for long periods of time.

Refer all servicing to qualified
services personnel. Servicing
is required when the apparatus
has been damaged in any way,
such as power-supply cord or
plug is damaged, liquid has
been spilled or objects have
fallen into the apparatus, the
apparatus has been exposed
to rain or moisture, does not
operate normally, or has been
dropped.

Adjust only those controls that
are covered by the operating
instructions as an improper
adjustment of other controls
may result in damage and will
often require extensive work by
a qualified technician to restore
the apparatus to its normal
operation

Damage Requiring Service
Unplug the apparatus from the
wall outlet and refer servicing
to qualified service personnel
under the following conditions:
When the power-supply cord or
plug is damaged; If liquid has
been spilled, or objects have
fallen into the apparatus; If the
apparatus has been exposed to
rain or water; If the apparatus
does not operate normally by
following the operating instruc-
tions; If the apparatus has been
dropped or damaged in any
way, and; When the apparatus
exhibits a distinct change in
performance this indicates a
need for service.

Object and Liquid Entry
Never push objects of any kind
into the apparatus through
openings as they may touch
dangerous voltage points or
short-out parts that could result
in a fire or electric shock. The
apparatus shall not be exposed
to dripping or splashing and no
objects filled with liquids, such
as vases shall be placed on the
apparatus. Don’t put candles or
other burning objects on top of
this unit.

This device has no power switch.
To disconnect this device from
power supply, the power cord
must be disconnected.

The power supply and power
cord for this apparatus is in-
tended for indoor use only.

Only use the included A/C adap-
tor.
Troubleshooting Guide
Once your subwoofer is set up, you should have many years of maintenance free enjoy-
ment from your system. However, if you should encounter a problem, refer to the fol-
lowing guide to help you find the solution. If a problem persists, you should contact
your local authorized Atlantic Technology dealer.
Problem Solutions
WA-50-t and/or WA-50-r
are connected but Status
LED does not light up a. Make sure both transmitter and receiver are con-
nected to a power supply
b. USB 2.0 connection on receiver or processor is being
used for power
c. Switch to supplied USB AC Adapter
No Wireless Connection
(WA-50-t and WA-50-r
Status lights are “Red”) a. Make sure your WA-50-t and WA-50-r are both set
to the same “Zone”
b. WA-50-r may be out of range. Try moving the
receiver closer
Your WA-50-t and WA-
50-r are connected, but
no audio occurs a. Ensure that your source components are function-
ing properly
b. Ensure that the audio levels are configured for au-
dible output (volume at source and/or destination
may be muted or turned too low)
c. If source component is computer, be sure the USB
Headset is still listed as Default Playback Device (See
PC and MAC configuration)
Package Content
