Lenovo H415 Desktop User Manual
Page 20
15
Hardware Replacement Guide
Memory connectors (2)
Thermal sensor header connector
Power connector
SATA connectors (4)
Front panel connector
Front USB connectors (3)
Serial(com2) connector
Front audio connector
PCI express X 1 adapter connectors (3)
PCI express X 16 adapter connector
System fan connector
12V power connector
Lenovo H410
14
15
Microprocessor and heatsink
