SUPER ‘’S’’ CROSS GRAIN SHEETER/MOULDER/PANNER
Sheeter Section
• Stainless steel construction.
• Slanted infeed conveyor with Teflon®
coated dough guides.
• Adjustable flattener roll.
• Removable D.C. variable speed stainless steel flour
sifter with automatic cut-off. (optional A.C.)
Shown with optional new larger dough spacer.
Moulder Section
• High speed transfer conveyor.
• Fully adjustable plow and curling mat.
• Smooth high speed transfer of product.
• Delrin transfer plate *Super “S” users have confirmed
speeds of 120 LPM for prolonged periods of time.
Above shown with high speed transfer conveyor.
• Stainless steel motorized pressure board.
• Air operated lifting device
(optional shown left) permits:
- Rapid change over of dough guides.
- Easier access for sanitation and maintenance
purposes.
• Easily adjustable pan guides.
FLOUR SIFTER 28"
30-1/2"
MOULDER PANNER
MAKE-UP BELT
HAND TWIST TABLE
HAND TWIST TABLE TRANSFER BELT
2" CLEARANCE
PANNER
SHEETER
NEW LARGER DOUGH SPACER
7'-2"
8'-7"
22-3/4"
24-1/4"
6-1/4"
• STAINLESS STEEL CONSTRUCTION
• EQUIPMENT MEETS OSHA REQUIREMENTS
• WORKING RANGE: 6 OZ. TO 36 OZ. / 7" TO 19"
RH MACHINE SHOWN
