Lenovo Yoga Tablet 8 B6000 User Manual
Page 58
Lenovo B6000/B8000 Hardware Maintenance Manual
54
12.
Remove the main antenna from the main PCBA.
Figure 8-12 Main antenna removed
13.
Disconnect the RF cable of the WiFi antenna from its connector on the main
PCBA and remove the WiFi antenna.
Figure 8-13 Disconnecting the RF cable of the WiFi antenna
Step
Screw (quantity)
Color
Torque
Phillips flat-head, M1.4 × 1.5mm (6)
Black
N/A
a
