Page 8
Compressor Load
(White)
Ground (Black)
+
-
60A Fuse
(Fused) Positive
Power Source (Red)
Toggle Switch
Trigger/Switch Positive
(Small Red)
Air Compressor
12V Battery
HORNBLASTERS
HORNBLASTERS
HORNBLASTERS
HORNBLASTERS
5/16” Air Line
5/16” Air Line
5/16” Air Line
5/16” Air Line
5/16”
A
ir Line
Hornblasters, Inc.
4532 W. Kennedy Blvd #233
Tampa, FL 33609-2042
Phone: +1 (813) 783-8058
Fax: +1 (813) 783-2407
email: [email protected]
5 Gallon Dual Conductor’s Special Installation Diagram
Ignition Wire
Run this wire to an ignition wire (this is a wire that
is only powered when the key is turned to the on
position). This will insure that the air compressor
will not run when the car is turned off and drain
your batteries.
Drain Cock
30
87/87a
85
86
30
87/87a
85
86
12V Fused
Air Compressor
Power
(Red or Black)
Ground (Black)
Load (R
ed)
Load (R
ed)
HORNBLASTERS.COM
AIR TANK
Pr
essur
e
Swit
ch
Ground (Black)
Ground (Black)
Port Plug
Port Plug
To Tank
