Kramer Electronics XE-21C - Manual

P/N: 2900-000912
Your XE-21C 2x1 Component Video Switcher
Congratulations on purchasing your XE-21C, which is intended for presentation and home
theater applications. Your XE-21C is a mechanical (passive) 2x1 Component Video
Switcher that switches one of two component video signals to a single output on RCA
connectors. Alternatively, the XE-21C can be used to switch composite video with stereo
audio (L, R) signals.
Connecting the XE-21C 2x1 Component Video Switcher
To setup your XE-21C, connect:
1. Up to two component video sources (for example, DVD players) to the input RCA
connectors.
2. The output RCA connectors to an acceptor (for example, a display).
Note:
Use good quality connection cables to avoid interference, deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables) and position your product away from moisture, excessive sunlight and dust.
Caution – No operator-serviceable parts inside unit.
For assistance, contact your dealer. Product Warranty is for one year.
