Installing and Removing the
SFP-IN/OUT-2km Fiber Optic
Module
Thank you for purchasing the Kramer SFP-IN/OUT-2km Fiber Optic Module that is used
in applicable Kramer fiber optic devices.
To install an SFP module:
1. Make sure the bail (removal handle) is closed
in an upward position as shown in #1.
2. Insert the SFP module in an open slot and
push it inward until it clicks.
3. Remove the protective SFP cap from the end
of the SFP (#2).
To remove an SFP module:
1. Pull the bail downward to release the SFP
(#3).
2. Pull the SFP module out by the bail (#4).
3. If needed, replace the protective cap over the
fiber connectors.
Note: When transporting or storing an unconnected device, replace the SFP caps to protect against dust.
