4x1V and 4x1VB - Connecting and Operating the 4x1V and 4x1VB 5
4 Connecting and Operating the 4x1V and
4x1VB
To connect the 4x1V and 4x1VB as illustrated in the example in Figure 2 :
1. Connect up to four composite video sources to the IN 1 to IN 4 connectors
(for example, composite video players).
You do not have to connect all inputs.
2. Connect the OUTPUT connector to a composite video acceptor (for
example, a composite video recorder).
Note: The 4x1V uses RCA connectors. The 4x1VB uses BNC
connectors.
To operate the 4x1V and 4x1VB:
Press an INPUT SELECTOR button to switch the desired source to the output.
