Parts Listings and Cross-Sectionals
Item Part name Material
412M 1 O-ring – containment shell Standard: Viton
Optional: EPDM
Optional: Teflon-encapsulated Viton
Optional: Chemraz 505
Optional: Kalrez 4079
426A Hex capscrew – casing drain 304 SS
492A Access hole plug Steel
740B Drive magnet assembly Cast iron / neodymium iron
750 Containment shell Tefzel / fiber-reinforced vinylester
1 Recommended spare parts
Item Part name Material
228 Frame, close coupled (IEC) Ductile iron
333L Setscrew 304 SS
371 Hex capscrew – motor to frame Carbon steel
388T Hex capscrew – adapter to frame 1 Carbon steel
408A Plug – drain Carbon steel
492A Plug – access hole Carbon steel
503 Ring – adapter 1 Cast iron
742B Ring – centering 2 Carbon steel
1 Used with motor frame 132 and 160 only.
2 Used with motor frames 80 and 90 only.
