VOCIA 8-CHANNEL LIVE AUDIO INPUT DEVICE (VI-8) SPECIFICATIONS
Network Audio:
20-bits, 48kHz, 5-1/3ms (fixed)
Network Connections:
Dual RJ45 with shielded Ethernet cable
(CAT5, CAT5e, CAT6, or CAT7)
Frequency Response (20Hz-20kHz):
+0, - 1dB
THD + N (20Hz to 20kHz):
<0.05%
Dynamic Range:
>100dB
Equivalent Input Noise:
< -125dBu
Crosstalk (10kHz):
< -75dB
Input Impedance:
8k
Ω
Maximum Input Level:
24dBu
Phantom Power:
48V DC behind 6.8k
Ω per leg
A/D Converters:
24-bit (48kHz sampling)
Power:
DC Input:
24V; <100mV Ripple; 35W
DC Reference Output:
24V; 100mA limited
Control Inputs:
Quantity:
9
High Range Logic Low:
0-8V DC
High Range Logic High:
12-30V DC
TTL Logic Low:
0–0.8V
TTL Logic High:
2-5V
Contact Closure:
10V Internal Reference
Input Transient Protection:
± 8kV Peak
Input Isolation:
500V RMS
Control Outputs:
Quantity:
4
Type:
Form C Voltage free change over contact
Max Operating Voltage:
125VAC, 60VDC
Max Switching Capacity:
37VA
Min Operating Load:
10μA @ 10mV DC
Status Out:
Type:
FET Switch, open drain (low side driver)
Max Operating Voltage:
35V
Max Continuous Current:
0.35A
Current Limit:
0.8A
Dimensions:
Height:
1.75 inches (44.5mm)
Width:
19 inches (483mm)
Depth:
10 inches (254mm)
Weight:
6.6 lbs. (3kg)
Environment:
Ambient Operating Temperature Range::
18-108 degrees F
(-8 – 42° C)
Altitude:
0–10,000 Feet (0-3000 meters) MSL
Humidity:
0 – 100% non-condensing
Compliance:
FCC Part 15B (USA)
ICE marked (Europe)
UL and C-UL listed (USA & Canada)
RCM (Australia)
EAC (Eurasian Customs Union)
RoHS Directive (Europe)
