Audio-Technica ATW-T310B - Manual (Page 7)

3000 Series Installation and Operation
7
UniPak ® Transmitter Functions
Function
Menu Default
Setting* Choices
(Edit)
▲▼
Wrap-around
(Transmitter powers-up at Frequency)
▲▼ Frequency Lowest in
band† All frequencies
in band Yes
▲▼ RF Power RF LOW RF LOW, RF HI Yes
▲▼ Audio Input
Level
+6 dB –6 dB, 0 dB,
+6 dB, +12 dB No
▲▼ Power/
Mute Locks
NO.LOC NO.LOC, ALL.LOC,
MUT.LOC,
PWR.LOC Yes
▲▼ Input Select MIC MIC, INST Yes
▲▼ Group 1 Lowest in
frequency
group All frequencies
in Group 1 Yes
▲▼ Group 2 Lowest in
frequency
group All frequencies
in Group 2 Yes
▲▼ Group 3 Lowest in
frequency
group All frequencies
in Group 3 Yes
▲▼ Group 4 Lowest in
frequency
group All frequencies
in Group 4 Yes
▲▼ Group 5 Lowest in
frequency
group All frequencies
in Group 5 Yes
▲▼ Group 6 Lowest in
frequency
group All frequencies
in Group 6 Yes
▲▼ Group 7 Lowest in
frequency
group All frequencies
in Group 7 Yes
▲▼ Group 8 Lowest in
frequency
group All frequencies
in Group 8 Yes
▲▼ Group 9 Lowest in
frequency
group All frequencies
in Group 9 Yes
▲▼ Reset to
Defaults
PRESET LOAD (b) hold
until: DEF (c)
hold until:
LOADED –
▲▼ Quit
(exit Menu)
QUIT Press Set to
exit –
Handheld Transmitter Functions
Function
Menu
Default
Setting* Choices
(Edit)
▲▼
Wrap-
around**
(Transmitter powers-up at Frequency)
▲▼ Frequency Lowest in
band† All frequencies
in band Yes
▲▼ RF Power RF LOW RF LOW, RF HI Yes
▲▼ Audio Input
Level
Dynamic
Condenser**
+6 dB
+6 dB
-6 dB, 0 dB,
+6 dB, +12 dB,
0 dB, +6 dB,
+12 dB No
No
▲▼ Power/
Mute Locks
NO.LOC NO.LOC, ALL.LOC,
MUT.LOC,
PWR.LOC Yes
▲▼ Group 1 Lowest in
frequency
group All frequencies
in Group 1 Yes
▲▼ Group 2 Lowest in
frequency
group All frequencies
in Group 2 Yes
▲▼ Group 3 Lowest in
frequency
group All frequencies
in Group 3 Yes
▲▼ Group 4 Lowest in
frequency
group All frequencies
in Group 4 Yes
▲▼ Group 5 Lowest in
frequency
group All frequencies
in Group 5 Yes
▲▼ Group 6 Lowest in
frequency
group All frequencies
in Group 6 Yes
▲▼ Group 7 Lowest in
frequency
group All frequencies
in Group 7 Yes
▲▼ Group 8 Lowest in
frequency
group All frequencies
in Group 8 Yes
▲▼ Group 9 Lowest in
frequency
group All frequencies
in Group 9 Yes
▲▼ Reset to
Defaults
PRESET LOAD (b) hold
until: DEF (c)
hold until:
LOADED --
▲▼ Quit
(exit Menu)
QUIT Press Set to
exit –
* Continue in the same Up/Down direction and choices “wrap around”
to the other end of the range.
** Additional 6 dB pad switch on capsule.
† Band I: 482.000 – 507.000 MHz; Band C: 541.500 – 566.375 MHz;
Band U: 606.000 – 631.000 MHz; Band D: 655.500 – 680.375 MHz;
Band G: 721.500 – 746.375 MHz; Band E: 795.500 – 820.000 MHz;
Band F: 840.125 – 864.900 MHz
