- 8 -
Before Use
Names and Functions of Main Parts
1 Flash (P59)
2 Self-timer indicator (P64)
AF Assist Lamp (P99)
3 Lens (P6 , 182)
4 Speaker
•
Be careful not to cover the speaker with your
finger. Doing so may make sound difficult to
hear.
5 Lens barrier
6 Monitor (P56 , 163 , 182)
• Peel off the protective film before use.
7 [EXPOSURE] button (P67 , 68 , 69)
8 Charging lamp (P13)
Wi-Fi ® connection lamp (P123)
9 Motion picture button (P34)
10 [(] (Playback) button (P37)
11 [MENU/SET] button (P41)
12 [Q.MENU] button (P43)
[ ] (Delete/Cancel) button (P40)
13 [DISP.] button (P56)
14 Cursor buttons
A: 3/[ È ] (Exposure compensation/Auto
Bracket) (P65 , 66)
B: 4/[#] (Macro Mode/AF Tracking) (P63 , 96)
C: 2/[ ë ] (Self-timer) (P64)
D: 1/[ ‰ ] (Flash setting) (P59)
In this owner’s manual, the cursor buttons are described as shown in the figure below
or described with 3/4/2/1.
e.g.: When you press the 4 (down) button
or Press 4
1 2 4
5
3
6 8 7 9 10
12 13 14
11
