Assembling & setting up the pedestal – Panasonic TYST50PX500 User Manual
Page 10
English
10
Fastening
Loosening
Fastening band
Keep the knob pressed.
To tighten.
Band
5. Attach the bands.
Band
Mains Lead
6. Connect cables and Mains lead fixing.
Example of “connection cable routing”
Insert the spigot on the two bands
into the
pedestal.
Connect power plug to the socket of the
main body.
Fix the mains lend in clamper.
How to fix:
How to release:
Fix by pushing in till a
clicking sound is heard.
Pull up while drawing the knob.
7. Fit the cable cover.
Insert the claws (at 2 points) at the bottom end.
Push it until hook will be cricked.
Assembling & setting up the pedestal
