7
Agilent G1978B Multimode Source for 6100 Series Single Quad LC/MS
Set-Up Guide
Agilent Technologies
1
Installation
Installation 8
Step 1. Prepare to install 8
Step 2. Install the HV control PCA and cables 9
Changing Sources 13
To remove the multimode source 13
To convert from multimode to ESI, APCI or APPI 14
To convert from ESI, APCI or APPI to the multimode source 15
This chapter contains instructions to install the multimode source on a 6100
Series Single Quad LC/MS system, and also to remove and replace the source.
