Sony XM-D400P5 - Manual (Page 2)

2003 SONY MOBILE
PRODUCT GUIDE
XM-D400P5
1 Channel Mono Amplifier
Design and Specifications subject to change without notice.
Connections
Dimensions Unit: mm (in.)
202 (8)
347 (13 3
4
)
311 (12
1
/ 4
)
119 (4
3
/ 4
)
327 (12 7 /
8
)
6 ( 1 /
4
)
339 (13
3
/ 8
)
57 (2 1 /
4
)
290 (11 )
1 /
2
264 (11 )
1 /
2
101 (4)
295 (11 ) 5/8
172 (6 ) 7/8
278 (11)
Subwoofer OUT
Through Output
2 - 30A fuses
Ground
12V Car Battery
Remote Output
Line Input
High Level Input Connection
