D-NS313F_2-689-469-11(1)_GB
Playing order
The playing order may differ depending on the method used to
record MP3 files on the disc. In the following example, files are
played in order of
1
to
7
.
10
MP3
Group
File
(Maximum directory levels: 8)
Notes
• Depending on the quality of the disc and/or the condition of the
recording device, it may take a while for playback to start. It is
also possible playback may not start at all.
• On a disc that has MP3 files, do not save files in other formats
and do not make unnecessary folders.
• Be sure to add the file extension “mp3” to the file name.
However, if you add the extension “mp3” to a file other than
an MP3 file, the player will not be able to recognize the file
properly.
• To compress a source in an MP3 file, we recommend setting
the compression parameters to “44.1 kHz,” “128 kbps,” and
“Constant Bit Rate.”
• To record up to the maximum capacity, set the writing software to
“halting of writing.”
Power Sources
To use the batteries (not supplied)
1 Unfasten the buckle to open the player lid and open the battery
compartment lid inside the CD player (
, ).
2 Insert two LR6 (size AA) alkaline batteries by matching the
to the diagram inside the CD player and close the lid until it
clicks into place. Insert the
end first (for both batteries) ().
Battery life* (approx. hours)
(When the CD player is used on a flat and stable place.)
Playing time varies depending on how the CD player is used.
When using two Sony alkaline batteries LR6 (SG)
(produced in Japan)
G-PROTECTION
G-on
G-off
Audio CD
16
11
MP3 CD (Recorded at 128 kbps)
23
23
RADIO ON
35
* Measured value by the standard of JEITA (Japan Electronics and
Information Technology Industries Association).
To check the remaining power of the batteries
You can check it in the display.
Replace the batteries when “
” flashes.
Lo batt
Notes
• The indicator sections of
roughly shows the remaining
battery power. One section does not always indicate one-fourth of
the battery power.
• Depending on operating conditions, the indicator sections of
may increase or decrease.
To use the AC power adaptor
Connect the AC power adaptor as illustrated (
).
Playing a CD
1 Unfasten the buckle to open the lid ().
2 Fit the CD to the pivot, then close the lid ().
3 While holding the lid closed, fasten the buckle securely ().
4 Press .
To play from the first track, press and hold
until
playback starts while the CD player is stopped.
To jump to the succeeding/previous groups*, press GROUP
first, then press
+ or
–.
*MP3 CD only
• This CD player can play CD-Rs/CD-RWs recorded in the
Compact Disc Digital Audio (Audio CD) format, but playback
capability may vary depending on the quality of the disc and
the condition of the recording device.
• This product is designed to play back discs that conform to the
Compact Disc (CD) standard.
Recently, various music discs encoded with copyright
protection technologies are marketed by some record
companies. Please be aware that among those discs, there are
some that do not conform to the CD standard and may not be
playable by this product.
• Depending on the CD, this player may display a total
number of files that includes both playable and unplayable
files. However, because the player skips unplayable files
automatically, only the playable ones will be played.
Note on DualDiscs
A DualDisc is a two sided disc product which mates DVD recorded
material on one side with digital audio material on the other side.
However, since the audio material side does not conform to the
Compact Disc (CD) standard, playback on this product is not
guaranteed.
Digital MEGA BASS function
During play, press SOUND/AVLS repeatedly to select “SND 1”
or “SND 2.”
If the sound is distorted, turn down the volume.
While listening to the radio, this function is disabled.
AVLS* function
*Automatic Volume Limiter System
Press and hold SOUND/AVLS.
If “AVLS” flashes three times, the function is enabled.
If “AVLS” flashes once, the function is disabled.
You can also use this function while listening to the radio.
AMS* / search function
*Automatic Music Sensor
To find the beginning of the previous/current/next/succeeding
track(s): Press
/ repeatedly.
To go backward/forward quickly: Press and hold
/.
Play mode function
During play, press P MODE/
repeatedly:
No indication (normal play)
“
(group play)”*
“1”(single
track play)
“SHUF”(shuffle play)
To repeat the play mode you selected, press and hold P MODE/
until “
” appears.
* All files in the selected group are played once. MP3 CD only.
G-PROTECTION function
The function provides protection against sound skipping during
many active uses.*
The default setting is “G-on.” To select “G-off,” press
while
you keep pressing
during stop. To enjoy high quality CD
sound, select “G-off”.
* Sound may skip: if the CD player receives stronger continuous
shock than expected / if a dirty or scratched CD is played / when
using poor-quality CD-Rs/CD-RWs or if there is a problem with
the recording device or application software.
To remove the CD
Remove the CD while pressing the pivot (
).
Listening to the Radio
1 Press RADIO ON/BAND to turn on the radio.
If “PRESET” appears on the display, press P MODE/
to
make “PRESET” disappear from the display.
2 Press RADIO ON/BAND until the band you want appears.
Each time you press the button, the display changes as
follows:
FM
AM
3 Press TUNE + or – to tune in the station you want and adjust the
volume.
Turning off the radio
Press
• RADIO OFF.
Tuning in the station quickly
Press and hold TUNE + or – in step 3 until the frequency digits
begin to change on the display. The CD player automatically scans
the radio frequencies and stops when it finds a clear station.
Improving broadcast reception
For FM, extend the headphones cord.
Headphones
For AM, reorient the CD player itself.
Note
Keep the headphones connected to the
jack of the CD player.
The headphones cord works as the FM antenna.
If it is hard to hear the FM broadcast due to
interference from strong radio waves
1 While listening to the FM broadcast, press SOUND/AVLS.
“LOCAL” flashes.
2 Press /ENTER within 10 seconds after you finished the
previous operation.*
“LOCAL” stops flashing.
* If “LOCAL” disappears from the display, start from Step 1.
To cancel the LOCAL setting, press SOUND/AVLS, and then press
/ENTER so that “LOCAL” disappears from the display.
If it is hard to hear the FM broadcast due to
poor reception
1 While listening to the FM broadcast, press SOUND/AVLS.
“LOCAL” flashes.
2 Press SOUND/AVLS again.
“MONO” flashes.
3 Press /ENTER within 10 seconds after you finished the
previous operation.*
“MONO” stops flashing.
* If “MONO” disappears from the display, start from Step 1.
To cancel the MONO setting, press SOUND/AVLS twice, and then
press
/ENTER so that “MONO” disappears from the display.
Presetting Radio Stations
You can preset up to 30 stations: 20 for FM and 10 for AM.
1 While listening to the radio, press P MODE/
to enter the
preset mode.
“PRESET” appears on the display.
2 Press TUNE + or – repeatedly until the preset number you want
appears on the display.
3 Press and hold P MODE/
until “PRESET” flashes on the
display.
From this step on, start the next operation within 30
seconds after you finished the previous operation. If
“PRESET” stops flashing, start from step 3.
4 Press TUNE + or – repeatedly to tune in the station you want.
5 Press /ENTER.
To cancel all preset stations
1 While the radio is turned off and CD play is stopped, press
RADIO ON/BAND while you are pressing
.
“CLEAr” flashes.
2 Press /ENTER.
Playing Preset Radio
Stations
1 Press RADIO ON/BAND to select the band.
2 When “PRESET” does not appear on the display, press
P MODE/
to enter the preset mode.
“PRESET” appears on the display.
3 Press TUNE + or – to tune in a stored station.
Changing the Tuning
Interval
When using the CD player abroad, change the AM tuning interval,
if necessary.
9 kHz area: Asia and Europe
10 kHz area: the U.S.A., Canada and Latin America
1 While the radio is turned off and CD play is stopped, press
RADIO ON/BAND while you are pressing
.
If the current setting is “9 kHz,” “10 kHz” flashes on the
display.
If the current setting is “10 kHz,” “9 kHz” flashes on the
display.
2 Press /ENTER.
Note
After changing the tuning interval, you need to preset radio stations
again.
Wearing the supplied
headphones
The following procedures are for wearing on the left ear.
1 Hook the L part over your left ear and the R part over your right
ear as illustrated.
2 Hook the headphones around your ears, as you would with
glasses.
3 Adjust the earpieces to comfortably fit your ears.
Notes on handling the supplied headphones
• Avoid rough handling or mechanical shock. Be particularly
careful of the headphone part.
• Do not put force or weight on the unit for a long time as that may
damage or deform the unit.
• Do not leave the unit in a location subject to moisture, dust,
smoke, steam or direct sunlight.
• Clean the plug with a soft dry cloth. A dirty plug may cause the
sound quality to deteriorate.
• Clean the headphone part with a soft dry cloth.
• After you use the headphones, keep them with the cord slider
positioned high to avoid entangling the cord.
Using the hand strap
During active uses, use the supplied hand strap.
1 Pass the end of the strap through the hole.
2 Put your hand through the strap, then adjust the length of the
strap.
SOUND/AVLS
RADIO ON/BAND
•
(group) –•
TUNE –
VOL +*/–
*(play/pause)/ENTER
Display
P MODE/
GROUP
•
(group) +•
TUNE +
(stop) • RADIO OFF
Open the battery compartment lid.
Insert the end first (for both
batteries).
Buckle
* The button has a tactile dot.
Label side up
HOLD (rear)
DC IN 4.5 V
(external power
input jack)
(headphones)
jack
to (headphones)
AC power adaptor (not supplied
with the model for USA)
to an AC outlet
Headphones
to DC IN
4.5 V
Playing time/ Frequency
Play mode
Remaining battery power
Track number/Preset number
Band
PRESET
Sound mode
LOCAL
MONO
Group indicator
FM/AM
Portable CD Player
Operating Instructions
2-689-469-
11 (1)
©2006 Sony Corporation
Printed in China
D-NS313F
“WALKMAN”,
, and
are registered trademarks of Sony Corporation.
Printed on 100 % recycled
paper using VOC (Volatile
Organic Compound)-free
vegetable oil based ink.
WARNING
To reduce the risk of fire or electric shock, do not expose this
apparatus to rain or moisture.
Do not install the appliance in a confined space, such as a
bookcase or built-in cabinet.
To reduce the risk of fire, do not cover the ventilation of the
apparatus with newspapers, tablecloths, curtains, etc. And do not
place lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do not place objects
filled with liquids, such as vases, on the apparatus.
CAUTION
The use of optical instruments with this product will increase eye
hazard.
Certain countries may regulate disposal of the battery used to
power this product. Please consult with your local authority.
The validity of the CE marking is restricted to only those
countries where it is legally enforced, mainly in the countries EEA
(European Economic Area).
For customers who purchased this product
in the USA
Owner’s Record
The model number and the serial number are located at the rear
of the CD player. Record the serial number in the space provided
below. Refer to these number whenever you call upon your Sony
dealer regarding this product.
Model No. D-NS313F
Serial No. _______________________
Product registration
Please register this product on line at www.sony.com/walkmanreg
Proper registration will enable us to send you periodic mailings
about software upgrades, new products, services and other
important announcements. Thank you.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician
for help.
You are cautioned that any changes or modifications not
expressly approved in this manual could void your authority
to operate this equipment.
Discs Playable on this CD
Player
•
Audio CDs (CD-DA format CDs)
•
MP3 CDs (CD-R/CD-RW on which audio data compressed in
the MP3 format has been recorded)*
* Only ISO 9660 Level 1/2 and Joliet extension format discs can
be played.
Bit rates and sampling frequencies this CD player can play are as
follows. Variable Bit Rate (VBR) files can also be played.
Bit rates
Sampling
frequencies
MPEG-1 Layer3
32 – 320 kbps
32/44.1/48 kHz
MPEG-2 Layer3
8 – 160 kbps
16/22.05/24 kHz
MPEG-2.5 Layer3
8 – 160 kbps
8/11.025/12 kHz
MP3 CDs
The usable number of groups and files
• Maximum number of groups: 256
• Maximum number of files: 512
