CDP-CA70ES

DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:

POWER
REQUIREMENTS:
POWER
CONSUMPTION:

FRONT VIEW

SIDE VIEW

5 CD
Changer

17" X 4 7/8" X 15 1/2"

15 lbs 6 oz

120VAC

V

60Hz

H

17 W

2 "

12 1/16"

2 "

17"

BACK VIEW

2 "

9 1/4"

2 "

AC Cord

15 1/2"

Sony Electronics Inc • Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX(201) 930-7891

Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.

1/2"

5/8"

4 7/8"

4 1/4"

5/16"

1/2"

1"

REMOTE
SENSOR

15"

3 2 00.3

CA7ES

CA7ES

NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS. SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .

CONTROL A1

Line
Out

Command
Mode

1 2 3

DIGITAL
OUT
