USER'S MANUAL
TECHNICAL SPECIFICATIONS
TV SYSTEM NTSC - M
POWER SUPPLY
AC Power Supply: 120V 60HZ AC
DC Power input: 6V DC 500mA
Battereries: 4xAA ALKALINE BATTERIES
or
4xAA NiMH BATTERIES
Built-In Battery charger: 2 Hour Quick Charge
SCREEN 1.8INCH (61,600 Pixel count)
TV FREQUENCIES
VHF band:channels:2-13
UHF band:channels:14-69
DIMENSIONS (WxHxD) 3 x 5.6 x 1.1 Inches
WEIGHT
0.40Lbs(without batteries)
CONTROLS, INDICATORS,AND CONNECTIONS
Charge indicator:Illumlinates when battreries are charging*
UHF/VHR Select/Power On/Off:Turns power on and off;Selects
UHF/VHF TV band
A/V IN:Allows you to input a composite video/audio signal into
the unit; requires 3.5mm to RCA adaptor (not included)
Earphone:3.5mm earphone jack; provides private listening
Antenna:Telescoping antenna for better reception
Speaker: Voice coil
6V DC In: DC input for charging and providing external power to
the TV
Battery Compartment:Holds 4 x AA alkaline batteries or 4 x AA
NiMH rechargeable batteries;Charge switch is located in the
battery compartment*
Channel +/-:Tunes the desired channel;press + to go up, - to
go down
Volume:Adjust the audio volume level up and down
Brightness:Adjusts the brightness of the image on the screen
Important Safety information
WARNING: DO NOT USE THIS PORTABLE SET WHILE
OPERATING A MOVING VEHICLE. THIS IS DANGEROUS,
AND MAY BE ILLEGAL IN SOME AREAS.
WARNING: TO PREVENT TO DAMAGE WHICH MAY RESULT IN
FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS SET TO
RAIN OR MOISTURE.
WARNING HIGH VOLTAGE PARTS ARE ACCESSIBLE
WHEN THE REAR PANELIS REMOVED.
WARNING:
THIS UNIT HAS A BUILT-IN BATTERY
CHARGER.PLEASE BE SURE TO SWITCH THE CHARGE
SWITCH IN THE BATTERY COMPARTMENT TO "OFF"
WHEN USING NON-RECHARGEABLE BATTERIES.
CHARGING OF NON-RECHAREABLE BATTERIES CAN
RESULT IN DAMAGE OR PERSONAL INJURY.
Care and maintenance
Clean the TV with a soft cloth occasionally. Do not use
harsh chemicals, cleaning solvents,or strong detergents.
Use only the power sources specified in this manual.
Use only new batteries of the recommended size. Always
remove the batteries if the TV will not be used for several
months as the batteries may leak chemicals that destroy the
TV's circuits.
Handle the TV carefully,dropping it could damage the
circuits or case.
Be extremely careful with the display screen. Avoid placing
the TV in your pocket or purse with objects that could
damage the screen.
Avoid places with extreme humidity, dust, or extremely high
or low temperatures.
Powering UP
AA ALKALINE BATTERIES:
Press the battery cover release tab and gently lift the battery
cover open.
Set the recharge switch located inside the battery
compartment to the "OFF" position
Insert four AA Alkaline batteries observing the
polarity symbols(+ and -) shown inside the battery
compartment.
Close battery cover.
*If using the AC adaptor with Alkaline batteries
installed in the TV, you MUST switch the
Recharge switch to the "OFF" position.
Failure to do so can result in personal injury or
damage.
Technical features
Power supply 4 x "AA" Batteries
or DC 6V
Display screen 1.8" (61,600pixel)
Weight 0.40Lbs
TV System NTSC
Model TFT - 1800
1.8" PORTABLE LCD TELEVISION
128-7101
