32
Printing the still image
You can print a still image by using the video printer (not supplied). Connect the video
printer using the A/V connecting cable supplied with your camcorder.
Connect the A/V connecting cable to the AUDIO/VIDEO jack and connect the yellow
plug of the cable to the video input of the video printer. Refer to the operating
instructions of the video printer as well.
Besides the video printer (not supplied), you can use the printer on your camcorder to
print images on the specified paper. (DCR-TRV820 only) (p. 104)
If the video printer is equipped with S video input
Use the S video connecting cable (not supplied). Connect it to the S VIDEO jack and the
S video input of the video printer.
S VIDEO
AUDIO / VIDEO
LINE IN
VIDEO S VIDEO
Recording a still image on a tape – Tape Photo recording
: Signal flow
Video printer
