Installation
Inserting Batteries into the Remote Control
Connecting the Aerial and VCR
Make sure you insert the supplied batteries using the correct polarity.
Always remember to dispose of used batteries in an environmentally friendly way.
• Use the supplied AC cable (Type BF).
• Use the supplied coaxial cable for aerial connection.
• Other connecting cables are not supplied.
For more details of VCR connection, please refer
to the section “Connecting Optional Equipment”
on page 28 of this instruction manual.
L/G/S/I
R/D/D/D
L/G/S/I
(SMARTLINK)
R/D/D/D
Y/G
P
B/
C
B/
B P
R/
C
R/
R HD
VD
L/G/S/I
R/D/D/D
CTRL S
(W/G/W/G)
AC IN
L/G/S/I
R/D/D/D
L/G/S/I
(SMARTLINK)
R/D/D/D
Y/G
P
B/
C
B/
B P
R/
C
R/
R HD
VD
L/G/S/I
R/D/D/D
CTRL S
(W/G/W/G)
AC IN
OUT
IN
or
Connect the supplied
cosxial cable.
VCR
Connect the supplied AC cable
(Type BF, with safety earth).
Scart lead is optional.
