MP6512i
6
FRONT PANEL RELEASE
The open button (1) releases the mechanism that holds the front panel to
the chassis.
Detaching the Front Panel
To detach the front panel:
1. Press and hold the power button (2) to turn the unit off.
2. Press and hold the open button (1). The panel will slide down.
3. Pull to release the right side of the panel.
4. Pull the left side of the panel to remove it.
5. After removing the front panel, store it in the supplied carrying case and
take it with you when you leave the car.
The motorized mechanism will close automatically after 10 seconds.
Re-attaching the Front Panel
To re-attach the front panel, make sure the electrical terminals on the back
of the panel are free of dust and dirt, as debris could cause intermittent
operation or other malfunctions. Position the right side of the panel in place
until correctly engaged, then lightly press the left side of the panel until the
mechanism locks it into place.
