QUICKSTART
5.964-011.0 07/11
6 A Sweeping damp or wet floors
A Fan "Off".
7 A B C Cleaning the dust filter
A Fan "Off".
B Depending on the amount of the collected
dust, the dust filter must be cleaned during
operation.
C Fan "On".
8 A Operation with working lights
A Switch on the working light.
9
C
A
D
B
E
Emptying waste container
ƽ Danger
Risk of injury! When emptying the waste
container, care should be taken to ensure that no
persons or animals are within its swivelling range.
ƽ Danger
Danger of crushing. Never reach into the rod
assembly for the drainage mechanism. Stay
away from the area under the raised container.
ƽ Danger
Danger of tipping! Place the appliance on an
even surface during the emptying
process.
A Keep the switch for the two-handed opera-
tions lift/tilt emptying mechanism pressed.
B Raise waste container.
C Tip waste container out.
D Tilt the waste container up to the end-position.
E Lower waste container.
Operation
