SPECIFICATION
Main Features
STB Type DVBC Receiver
Main Chipset ALI 3602
Special Features
Encrypt ASIC Type
TUNER Type ALPS TDAE2 /Thomson DCT7070X
Demodulator Type STV0297E
SMPS Type Separate SMPS
Mechanical
Dimension W:26.0 cm D:21.3 cm H:4.5 cm
Net Weight 1.5 kg
Main Chip Sets
CPU frequency 266MHz
Flash Memory 1PC 32Mbit/4Mbyte
SDRAM Memory 2PCS 32MX16bit/64Mbyte DDRs
DVBC Tuner
Tuner Type 50~858MHz
RF input IEC(F) Loop through:IEC M);Thomson
7070X/ALPS TDAE2
Frequency Range 50~858MHz
Input Impedance 75Ω
Input Level Range
-65dBm ~ -25dBm64QAM:<=34dBuV,>=95dBuV；
256QAM:<=42dBuV,>=90dBuV；
QAM64 60dBuV 6.875Mbps/5.057Mbps
BW:8/6MHz,<23.5; QAM256
60dBuV 6.875Mbps/5.057Mbps BW:8/6MHz,<30;
Loop-Through 50MHz~858MHz full Band loop through
DVBC Channel Decoder
DVBC Symbol Rate QAM16/QAM32/QAM64/QAM128/QAM256
DVBC Code Rate 8/6MHz
TS Demux
Demultiplexer MPEG2 ISO/IEC 13818-1
Input Bit Rate Max 100Mbit/s
Video Decode
Video Decode
MPEG2 ISO/IEC 13818-2 MP@ML, H.264(MPEG4 part 10)
main and high profile level 4.1/MPEG-2 MP@HL
Video Resolution 1920Ч1080,1280Ч720,720Ч480
Audio Decode
Audio Decode
MPEG-1 layerI/II, PCM downmix, IEC958 SPDIF, Dolby 5.1
channel, Dolby downmix 2 channel, Dolby Prologic2
Sampling Frequency 32KHz, 44.1KHz, 48KHz
AV Output
Video Bandwidth SD:5.0MHz(-3dB),HD:30MHz(-3dB)
Video Impedance 75Ω
Video Voltage Level 1.0 Vp-p
Audio Freq. Range 20 ~ 20KHz
Audio Impedance 600Ω
Audio Voltage Level 2V rms(5.6Vp-p)
Environment
Input Voltage AC 100~250V/50Hz/60Hz
Consumption Max 15W
Temperature 0~40
Humidity <95%
