Lexicon DC-2 - Manual (Page 3)

Lexicon, Inc.
DC-2/MC-1 Serial Communications Protocol
Printed on: 10/19/00
3 of 44
7.3.26 Set Custom Name 28
7.3.27 Set Input Name by Id 29
7.3.28 Set FPD Control Registers 30
7.3.29 Host Wakeup 30
7.3.30 Host Sleep 31
7.3.31 Get Communication Configuration 31
7.3.32 Set Communication Configuration 32
7.3.33 Set Mute 32
7.3.34 Set Output Level Adjustments 33
7.3.35 Send Display String Command 34
8 Internal Use 35
8.1.1 Debug Character 35
8.1.2 PEEK Command 35
8.1.3 POKE Command 35
9 Appendix A Command Codes 35
10 Appendix B Error Codes 37
11 Appendix C DC-2/MC-1 IR-Codes 38
12 Appendix D Input Id’s 39
13 Appendix E Protocol Constants 39
14 Appendix F FPD Control Registers 40
15 Application Notes and Examples 40
15.1 Box initializations: 40
15.1.1 DC-2/MC-1: 40
15.1.2 HOST: 40
15.2 Getting System Wide Status and Setup: 41
15.3 Downloading the System Setup to the DC-2/MC-1: 41
15.4 Simple System Control & System Status: 41
15.5 Examples: 42
15.5.1 Get Unit Configuration 42
15.5.2 Get Effect Definition 43
15.5.3 Set Input Name 43
15.5.4 Send IR Command Example 44
