8
Troubleshooting
Symptom Solution
No power to the monitor 1. Check that reverse power is
attached to orange wire.
2. Check that accessory power is
attached to red wire
3. Check that black is attached to
vehicle body (ground)
4. Check fuse and if blown
ONLY replace is fuse of same
amperage.
No image from backup camera
when vehicle placed in reverse 1. Check that camera is
functioning correctly
2. Check that orange wire is
attached to reverse power.
3. Check that backup camera is
attached to input CAM1.
Image is mirrored or requires
adjustment 1. All settings are adjusted by
pressing on the bottom right
corner of the screen (*Touch)
and following prompts.
Sound can not be heard from
Advent camera 1. Increase volume through touch
menu.
