5
Status LED
1. The Status LED on the Phottix Strato Multi transmitter
will turn solid green upon a half-press of the shutter
button (on camera or the Strato Multi transmitter being
used as a wireless shutter release) and turn red when
sending a signal or taking a photo
2. The Status LED on the Phottix Strato Multi receiver will
flash green while the power is on and idle. The LED will
turn red when a signal is received from the transmitter
and the flash or camera is fired.
Groups and Channels
1. The Phottix Strato Multi System has 4 groups: A, B, C,
and D. Each group contains 4 channels: 1, 2, 3, 4.
2. Receivers can be assigned both group and channel
designations.
3. The transmitter will fire groups A, B, C or D, or any
combination on the same channel: 1, 2, 3 or 4. Any
flashes or strobes connected to Strato Multi receivers
set to the same group(s) and channel as the transceiver
will fire.
Compatibility with Phottix Strato 4-in-
1 Wireless Triggers
Phottix Strato Multi System is compatible with the
Phottix Strato 4-in-1 Wireless receivers.
1. Phottix Strato 4-in-1 receivers can be triggered on
channels 1 to 4. They cannot be assigned groups and will
fire if the Strato Multi transmitter is set to groups A, B,
C or D.
2. The Phottix Strato 4-in-1 transmitter cannot trigger
Phottix Strato Multi receivers.
Setting Groups on the transmitter
1. The Phottix Strato Multi System has 4 groups: A, B, C,
and D.
2. Pressing the Group Selection Buttons on the
transmitter allow you to select with groups will be
triggered. Selected groups on the transmitter will trigger
receivers assigned that group and channel.
3. The Group Selection Button will turn red when pressed
and selected.
4. The green light (red light) will go off when pressed and
deselected.
En INSTRUCTION MANUAL
