Press this key to access the phase menu list.
Display Command Function
PHASE Set immediate output phase (
φ
)
PHASE:T Set triggered output phase (
φ
)
PHASE:M Select the phase mode (
φ
) (FIXED, STEP, PULSE or LIST)
Press this key to access the shape menu list.
Display Command Function
SHAPE Select the immediate output wave shape
1
(SINE, SQUARE,
or CSINE) CSIN = clipped sine wave
SHAPE:T Select the triggered output wave shape (SINE, SQUARE, or
CSINE) CSIN = clipped sine wave
SHAPE:M Select the shape mode (FIXED, STEP, PULSE or LIST)
CLIP Set the clipping level of the CSIN wave shape. This
specifies the point where clipping starts as a percentage of
the peak amplitude or percentage of THD.
Press this key to access the pulse menu list.
Display Command Function
WIDTH Set the pulse width
COUNT Set the number of output pulses
DCYCLE Set the pulse duty cycle as a percentage of the pulse period
PER Set the pulse period
HOLD Set the parameter that will be held constant as the other
parameters change (WIDTH or DCYCLE)
Press this key to access the output menu list.
Display Command Function
*RST Execute *RST command to place the ac source in the
factory-default state
TTLT:SOUR Select Trigger Out source coupling (BOT, EOT or LIST)
BOT = beginning of transient
EOT = end of transient
LIST = TTLT trigger (see Programming Guide)
TTLT:STATE Set Trigger Out state (ON or OFF)
PON:STATE Select power-on state command (RST or RCL0)
RI Sets remote inhibit mode (LATCHING, LIVE, or OFF)
DFI Sets discrete fault indicator state (ON or OFF)
DFI:SOUR Select the DFI source (QUES, OPER, ESB, RQS, or OFF)
(see
Chapter 4 of Programming Guide)
Notes:
1
User defined waveshapes will also appear in this list when created.
φ
= phase selectable on Agilent 6834B
value = a numeric value
char = a character string parameter
and scroll through the command list.
and scroll through the parameter list.
