CAUTION - This device complies with
part 15 of the FCC rules. Operation is
subject to the following two conditions.
(1)This device may not cause harmful
interference and (2) This device must
accept
any
interference
received,
including interference that may cause
undesired operation.
Transmitter Operation
NOTE:
Be sure to install 4 fresh
1.5-volt batteries(not included)
Fan- Pressing this button steps
through the various fan speeds "High",
"Med.", "Low" and "Off". The fan speed
is displayed on the LCD screen.
Light - Pressing this button activates
the light On and Off.
For/Rev- Reverses the fan's direction of
rotation.
Timer ºC / ºF- Automatically turns the
fan/ light off after a pre-selected amount
of time. Press the Timer button followed
by the Up and Down buttons to adjust the
time delay before the fan/light turns off.
To select Fahrenheit or Celsius, press
Timer button for at least 10 seconds.
Light Delay
- Pressing
this button
activates the light delay function. The
light will automatically shut off after 3
minutes.
Fan Auto and Temp./Set (Up and Down)
-Pressing the Fan Auto button places the
fan in automatic fan control mode. In this
mode the fan speed is automatically set
on "High", "Med." Or "Low" speed
depending upon the room temperature
and the user selected temperature set
point. Press the Temp Set Up and Down
buttons
to
select
the
desired
room
temperature. If the room temperature is
less than the set point then the fan turns
off, if the room temperature is within 3
degree F over/or equal to the set point
then the fan will be on "Low" speed. As
the room temperature increases the fan
will automatically switch to "Med" and
then "High" speed. For every 4 degree F
over the set temperature, the fan will
switch to the next higher speed.
Wall Mount- Your remote control model
comes with a holder included for the
transmitter which can be mounted on a
convenient location on a wall. (Figure 18).
The
holder
will
help
prevent
your
transmitter from being misplaced.
The remote control monitors the air
temperature to automatically control the
fan speed. Ideally local the control on an
interior wall where it will accurately read
the air temperature away from direct sun
or other heat sources.
FAN AUTO MODE SET POINT EXAMPLE:
SUMMER
WINTER
SET POINT
72º
75º
78º
80º
OFF
72º
74º
77º
79º
LOW
72º-75º 75º-78º 78º-81º 80º-83º
MED
76º-79º 79º-82º 82º-85º 84º-87º
HI
80º+
83º+
86º+
88º+
10.Operating Your Remote Control
