AirSep MN126-1 C User Manual
Page 52
5-26
AirSep Corp. — FreeStyle Service Manual
4. Following alignment, view the replacement board from the side at an angle to
make certain that the pins are aligned properly before seating the connector.
Figure 5.38
5. Gently press the board into place until properly seated.
(Figure 5.38)
Figure 5.39
