The Wireless Connectivity Expert
Serial-IR Dongle Installation Manual
ACTiSYS Confidential Information Version 1.5.1.1
1. OVERVIEW
This document provides instructions to install the ACT IR220L+/220L/200L Serial-IR dongle along with
Windows 98/ME/2000/XP device driver. It is assumed that the user is familiar with basic operation of
Windows.
2. PACKING LIST
When you unpack the package, the following items should be found:
A. ACT-IR220Lplus or ACT-IR220L or ACT-IR200L.
B. User’s Guide CD
3. SYSTEM REQUIREMENTS
To use ACT-IR220L+/220L/220L, your computer MUST meet the following requirements:
A. Windows 98/ME/2000/XP.
B. One unoccupied Serial (RS232) COM port.
C. One unoccupied virtual COM port (Com 4)
4. BIOS SETUP VERIFICATION
Before installing the device driver, you MUST setup or verify your BIOS FIRST.
Below demonstrates an example of ACT-IR220L+ being installed on Com2:
A. Choose PNP & PCI from BIOS SETUP:
PNP OS Installed: NO
Resource Controlled by: Manual
B. Choose Integrated Peripherals from BIOS SETUP:
Onboard UART2 Serial Port
2 : 2F8H/IRQ3
Onboard IR function: Disable or
UART2: Normal
© Copyright 2001-2008 ACTiSYS Corp.
Page 5 of 37 Jul. 8, 2008
