Technical specifications – NewAir AC14000E User Manual
Page 16

TECHNICAL SPECIFICATIONS
Model Number:
AC-14000E
AC-14000H
Power/Ampere Consumption
for Cooling*
1420W / 12.8A
Power/Ampere Consumption
for Heating*
N/A
1420W / 12.8A
450m
3
/h
Air Volume (max. speed)
Voltage / Frequency
115V, 60Hz
Compressor Type
Rotary
Refrigerant Type
R-410A
Number of Fan Speeds
3
Timer 1~24 hours
Exhaust Pipe Dimensions
Ø 5.6" X 59.1"
Net Weight
72.8 lbs
Product Dimensions
17.7" x14.4" x 32.5"
Notes:
1. Heating function is only for model number AC-14000H.
2. The data marked with '*' may vary for technical reasons; for more accurate data, please refer
to the rating label found on the back of the unit.
3. Measuring condition for the above specifications:
* D.B. = dry bulb temperature = room temperature
*W.B. = wet bulb temperature = relative humidity
15
Cooling – DB = 95° F , WB= 82.94° F
Heating – DB= 68° F , WB= 59° F
K0080-1-2
