Onboard PCI Device
Click key to enter its submenu:
Phoenix – AwardBIOS CMOS Setup Utility
Onboard PCI Device
IEEE 1394 Controller Enabled Item Help
Serial1 ATA Controller Enabled
- SATA RAID Mode Disabled
- SATA Option ROM Enabled
Serial2 ATA Controller Enabled
- SATA RAID Mode Disabled
- SATA Option ROM Enabled
LAN1 Controller Enabled
- Invoke Boot Agent Disabled
LAN2 Controller Enabled
- Invoke Boot Agent Disabled
↓↑→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
IEEE 1394 Controller (for model AW9D-MAX only)
This option enables or disables the IEEE 1394 controller.
Serial1 ATA Controller (for Connector “SATA5” and “SATA6” on model AW9D-MAX only)
This option enables or disables the Serial ATA controller.
- SATA RAID Mode
This item determines to enable or disable the RAID mode for onboard SATA controller.
- SATA Option ROM
This item allows you to use the boot ROM of onboard Serial ATA RAID to boot up system.
Serial2 ATA Controller (for Connector “SATA7” and “eSATA1” on model AW9D-MAX only)
This option enables or disables the Serial ATA controller.
- SATA RAID Mode
This item determines to enable or disable the RAID mode for onboard SATA controller.
- SATA Option ROM
This item allows you to use the boot ROM of onboard Serial ATA RAID to boot up system.
LAN 1 Controller
This option enables or disables the LAN1 controller.
3-24 AW9D-MAX, AW9D
