Specifications – Audiovox D1750T User Manual

Page 30

Text mode
Original mode

- 29 -

SPECIFICATIONS

TFT Screen Size

7 inches

Laser Wavelength

Wavelength: 780/650nm

Video System

NTSC

Frequency Response

20Hz 20KHz ±2.5dB

Audio Signal-To-Noise Rate

≥ 80 dB

Audio Distortion + Noise

≤ -70dB (1KHz)

Channel Separation

≥ 70dB (1KHz)

Dynamic Range

≥ 80dB (1KHz)

Audio Out

Analog Audio

Out Level: 1.5V±

0.2
1.0

, Load: 10KΩ

Video Out

Out Level: 1V

P-P

±0.1, Load: 75Ω

Unbalanced Negative

Power

AC100-240V 50/60Hz

Power Consumption

13W

Dimension w/o Battery

7.87”Ч6.06”Ч 1.6”/1.14” (L/W/H)

Weight w/o Battery

About 1.0kg / 2.2 Lbs

DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE
WITHOUT NOTICE

Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby Laboratories.
Confidential unpublished works.

1992 -1997 Dolby Laboratories.
