6
En
Checking Before the Setup
Wireless LAN Router
Internet
Is the computer connected to the router (or the access
point) correctly by a LAN cable or wireless LAN?
For more information, see the instruction manual for the
network device you are using, or contact the networking
device manufacturer.
Has the network settings on the computer been
completed?
If the computer is not properly configured, you may not use
the wireless LAN connection even after completing the
following settings.
NOTE
• You cannot connect both the wired LAN and wireless
LAN at the same time. In addition, the machine is set
to the "Wired LAN" by default.
• When you connect to a network environment that
is not security protected, your personal information
could be disclosed to third parties. Please use
caution.
• If you connect through a LAN in the office, contact
your network administrator.
• When proceeding from “Specifying the Initial
Settings” in the Starter Guide:
Proceed to "Checking the Router" on the right side of this
page.
Switching the Connection Method to
Wireless LAN
1
Press [ ] (Menu).
2
Select , and then press [OK].
3
Select , and then press [OK].4 Select , and then press [OK].Select LAN
Wired LAN Wireless LAN5 Restart the machine for the settings to take effect.ONOFF10 SecondsChecking the RouterSelect the connection method to the wireless LAN. Select from the following two methods depending on the router or the access point that you are using. There is a button.This machine supports WPS (Wi-Fi Protected Setup). You can easily set up if your router or access point has a button, and if the following mark is on the router. If you are not sure whetheror not your router supports WPS, please see the manual included in the product, or contact the product manufacturer.There is no button.If there is no button on your router/access point, you may manually select SSID and complete the settings. In this case, you need to remember SSID and network key of your router/access point.
See "Checking SSID or Network Key for a Wireless LAN Router/Access Point" (P.9) to learn how to find out your SSID and network key.
To set up with WPS PIN code method, or setup manually: e-Manual "Setting the Machine Using WPS (PIN Code Mode)" e-Manual "Setting by Manually Entering SSID"• When proceeding from “Specifying the Initial Settings” in the Starter Guide: Proceed to step 3 of "Setting Wireless LAN" (P.7). Pages: 1 … 4 5 6 7 8 … 120 wrong Brand wrong Model non readable This manual is related to the following products: i-SENSYS MF4890dw See also other documents in the category Canon Multifunction Devices: PIXMA MP250 (678 pages) PIXMA MP830 (222 pages) PIXMA MX870 (1127 pages) PIXMA MX340 (75 pages) PIXMA MG5220 (54 pages) PIXMA MP560 (949 pages) ImageCLASS MF4450 (164 pages) iR 2020 (92 pages) iR 2020 (20 pages) ImageCLASS 1100 (2 pages) PIXMA MX524 (339 pages) PIXMA MG7150 (300 pages) PIXMA MG7150 (31 pages) i-SENSYS MF8080Cw (276 pages) i-SENSYS MF3010EX (204 pages) i-SENSYS MF3010 (20 pages) i-SENSYS MF3010 (204 pages) PIXMA MG6450 (25 pages) PIXMA MG6450 (4 pages) i-SENSYS LBP6780x (2 pages) i-SENSYS LBP7110Cw (2 pages) PIXMA MX524 (335 pages) PIXMA MX454 (4 pages) i-SENSYS MF5940dn (9 pages) i-SENSYS MF5940dn (288 pages) i-SENSYS MF8380Cdw (128 pages) i-SENSYS MF5980dw (128 pages) i-SENSYS MF5940dn (9 pages) i-SENSYS MF5940dn (40 pages) PIXMA MG3550 (5 pages) PIXMA Pro9500 Mark II (303 pages) PIXMA Pro9000 Mark II (36 pages) i-SENSYS LBP7680Cx (2 pages) i-SENSYS LBP6680x (2 pages) PIXMA Pro9500 Mark II (36 pages) PIXMA MG5550 (25 pages) PIXMA MG5550 (4 pages) PIXMA MX394 (4 pages) PIXMA MX924 (4 pages) PIXMA MX924 (4 pages) PIXMA MG7150 (27 pages) PIXMA MG7150 (4 pages) PIXMA MX524 (4 pages) PIXMA MX524 (4 pages) i-SENSYS MF8540Cdn (120 pages) Sitemap
press [OK].
4
Select , and then press [OK].
Select LAN
Wired LAN
Wireless LAN
5
Restart the machine for the settings to take effect.
ON OFF
10 Seconds
Checking the Router
Select the connection method to the wireless LAN. Select
from the following two methods depending on the router or
the access point that you are using.
There is a button.
This machine supports WPS
(Wi-Fi Protected Setup). You
can easily set up if your router
or access point has a button,
and if the following mark is on
the router.
If you are not sure whetheror not your router supports WPS,
please see the manual included in the product, or contact the
product manufacturer.
There is no button.
If there is no button on your
router/access point, you may
manually select SSID and
complete the settings. In this
case, you need to remember
SSID and network key of your
router/access point.
See "Checking SSID or Network Key for a Wireless LAN
Router/Access Point" (P.9) to learn how to find out your SSID
and network key.
To set up with WPS PIN code method, or setup
manually:
e-Manual "Setting the Machine Using WPS (PIN Code
Mode)"
e-Manual "Setting by Manually Entering SSID"
• When proceeding from “Specifying the Initial
Settings” in the Starter Guide:
Proceed to step 3 of "Setting Wireless LAN" (P.7).
