Routine Maintenance
108
4
You will need to clean the machine regularly and replace the consumable items when the following messages
are displayed on the LCD.
1 Letter or A4 size single-sided pages.
2 Approx. cartridge yield is declared in accordance with ISO/IEC 19798.
3 1 page per job
4 Drum life is approximate and may vary by type of use.
5 Standard toner cartridge
6 High yield toner cartridge
LCD messages Consumable
item to replace Approximate life How to replace Order No.
Replace Toner
Toner cartridge
2,500 pages
1 2 5
Yellow>
1,400 pages
1 2 5
2,200 pages
1 2 6
See page 111
TN-221BK
5
TN-221C
5
TN-225C
6
TN-221M
5
TN-225M 6
TN-221Y 5
TN-225Y 6
Replace Drums
4 Drum units
15,000 pages 1 3 4 See page 119 (4 Drum units)
DR-221CL
(1 Drum unit)
DR-221CL-BK
DR-221CL-CMY
Replace Drum: X
1 Drum unit
X
= C, M, Y, BK
C
= Cyan
M
= Magenta
Y
= Yellow
BK
= Black
15,000 pages 1 3 4 See page 119
Drum Stop
Drum unit
15,000 pages
1 3 4 See page 119
Replace Belt
Belt unit
50,000 pages
1 See page 128 BU-220CL
Replace WT Box
Waste toner box
50,000 pages
1 See page 133 WT-220CL
Replace Fuser
Fuser unit
50,000 pages
1 Call Brother Customer Service for a
replacement fuser unit.
Replace PF kit1
Paper feeding kit
50,000 pages
1 Call Brother Customer Service for a
replacement paper feeding kit 1.
