Prochem Peak GTX User Manual
Page 81
79
86325860 PEAK GTX PROCHEM
Solution Outlet
REF
PART NO.
QTY
DESCRIPTION
SERIAL NO.
FROM
NOTES
1
86187220
1
MANIFOLD, SOLUTION
2
86190180
1
PLG,1/8 SOCHD BR
3
86010780
4
WASHER, 1/4 SPLIT
4
86274750
4
SCR, 1/4-20 X 3/4 HHCS
5
86247680
1
NIPPLE, 1/4 HEX
6
86002450
1
COUPLER, 1/4 QD
7
86192490
1
SENDER, TEMP 140-320 DEG
8
86175920
1
BUSH, 3/8 X 1/8 BR
9
86180420
1
ELL, 1/8P X 1/4T 45 DEG
10
86180410
1
ELL, 3/8P X 1/2T BR
11
86177660
1
CONN, 1/8P X 1/4T
12
86272720
1
PLG, 1/4 SOCHD BRASS
13
86190520
1
PLUG, 3/8 SOCHD BR
14
86192240
1
SCRN, MESH W/O-RING, SOL MNFLD
INCLUDES 15, 16
15
86192210
1
SCREEN, CHECK VALVE
16
86189260
1
O-RING
17
86195030
1
VALVE, CHECK
INCLUDES18-24
18
86189230
1
O-RING
19
86192390
1
SEAT, CHK VLV ASSY
20
86194250
1
TEFLON SEAT
21
86190910
1
POPPET, CHK VLV ASSY
22
86193260
1
SPRING
23
86189270
1
O-RING, 7/8 ID 1-1/16 OD
24
86176350
1
CAP
