THE METRON RANGE
METRON
METRON A
4 static outputs 0/24V with programmable functionality through Metronconf Software.
M12, 8-pole connector on emitter, M16, 12-pole on receiver.
PC-programmable through interface RS232 (with M8, 3-pole connector on receiver).
Ideal solution for obtaining simple on/off data upon occurrence of programmed conditions.
Ideal for identification of objects, quality control, detection of dimensional limits.
METRON B
Serial line RS-485 + 2 static outputs 0/24V with programmable functionality through Metronconf Software.
M12, 8-pole connector on emitter, M16, 12-pole on receiver.
PC-programmable through interface RS232 (with M8, 3-pole connector on receiver).
Solution providing data on the status of each beam through serial line RS 485 and, through 2 static outputs, further on/off data
upon occurrence of programmed conditions.
Ideal for dimensional measurements, detection of outline and position of objects.
METRON C
2 static outputs, 0/24V antivalent, no need of programming.
M12, 5-pole connector, on emitter and receiver.
Ideal solution for obtaining simple on/off data on status of guarded area.
Ideal for counting and detection of object present/absent in controlled field.
Photoelectric light curtains for industrial and civil applications requiring detection, measurement and
identification of objects.
METRON will provide information for:
▪Detecting objects
▪Counting items
▪Defining position
▪Identifying shape or outline
▪Measuring dimensions.
For programming models A and B each light curtain is provided with PC-compatible configuration
Software Metronconf, with practical graphic interface.
Main features:
▪Monitored height 140 to 2525 mm
▪Beam spacing available: 5-10-25-30-50-75 mm
▪Max range - 2 m for models with 5 mm center distance
- 6 m for models with 25-50-75 mm center distance
- 16 m for models with 10-30 mm center distance
▪IP 65 protection rate
▪Operating temperature range: 0 to 55 °C
▪Cross section 35 x 45 mm.
Special models to “Directive ATEX” 94/9/EC - Dust Zone 22 - Gas Zone 2 available on request.
Special versions with watertight enclosure rate IP 67 (WT and WTH) available.
