Airedale Air Cooled Condensers R407C - Manual (Page 4)

C11-45 / CS50 - 105 CONDENSERS
4
Condensers
Technical Manual: 6469597 V1.3.0 02_2013
\CONTENTS
Contents
General Description 5
Unit Identification 5
Introduction 5
Standard Features 6
Optional Extras 7
General Specification 8
Mechanical Data 8
Electrical Data 10
Interconnecting Wiring 10
Performance Data 11
Capacity Data 11
Operating Limits 11
Sound Data 12
Method of Sound Measurement 12
Sound Data 12
Dimensional & Installation Data 13
Dimensions / MASSES / Positioning - Horizontal 13
Dimensions / MASSES / Positioning - Vertical 14
Unit Lifting 17
Siting Recommendations 17
