Alps Electric SPPW8 - Manual

Power
20
Detector
Push
Slide
Rotary
Encoders
Dual-in-line
Package Type
Multi Control
Devices
TACT Switch TM
Custom-
Products
One-way operation detector switch ideal for media detection.
Reflow and dip solderable.
Reflow solderable type can be packaged and delivered in carrier
taping. (Except for slider hight-10, 3mm products)
Features
For detecting mechanisms in DVD players/recorders and facsimile
machines
For detecting the insertion of various media in portable CD/MD
players
For detecting battery lids in digital still cameras
For massage machine remote controllers
Applications
One-way Operation Type
SPPW8
Series
SPPW812302
SPPW812300
SPPW810201
SPPW810203
SPPW811203
SPPW811200
SPPW810401
SPPW810400
Operating life
0.1A 30V DC/100BA 3V DC
0.3N max.
1 max./2 max.
100,000cycles
Rating max. min. Resistive load
Items Specifications
Contact resistance
Initial /After operating life
Operating force
100,000cycles 0.1A 30V DC
Without load
With load
Typical Specifications
Product Line
Poles
1 1
h=6.1
h=6.55
h=7.6
h=10.3
Positions Product No.
Slider height
mm
h
1
=5.6
h
1
=6.05
h
1
=7.1
h=9.8
ON start
position mm
h
2
=4.45
h
2
=4.85
h
2
=5.9
h=8.6
Total travel
mm
Terminal type
1
2
1
2
1
2
3
4
Drawing
No.
For PC board
Reflow
For PC board
Dip
For PC board
Reflow
For PC board
Dip
For PC board
Reflow
For PC board
Dip
For PC board
Reflow
For PC board
Dip
Refer to P.67 for product specifications.
Refer to P.71 for taping package specifications.
Products other than those listed in the above chart are also available. Please contact us for details.
Note
Detector Switch
