5A 250V AC Qualified Primary Input Voltage Selection Type
SDKP
Series
Ratings and Safety Standards
UL
CSA
Items Specifications
SEMKO
Ratings satisfying local electrical
appliance and material safety law
Product Line
5A 250V AC
5A 250V
250V 5A2
Circuit
arrangement
DPDT 10 N 10
5
Right
angle
Operating
force
Travel
mm
Mounting
method
Terminal
configuration
Without
With
Without
With
Turn
stopper
Without
marking
Marking
variety
100
Minimum
packing unit pcs.
Product No.
Drawing
No.
1
2
SDKPA40100
SDKPA40200
1 SDKPA40300
2 SDKPA40400
6
Self-tap
for M2.6
Self-tap
for M3
Refer to P.267 for product specifications.
Primary voltage changeover switch replacing the SDKG.
Dimensions, mounting configuration and the terminal layout
specifications are compatible to the SDKG series.
No cadmium used in contacts.
Complies with safety standards in each country (C-UL-US and
SEMKO).
Features
For switching primary input voltage according to the export
destination -for speaker systems, receivers and various audio
equipment
Applications
Power Switch
